One Day Old Baby Chick Cage With Full Automatic System
Layer Cage with drinking system include :
1: Wire mesh (Hot and cold galvanzied material)
2: Hot galvanized frame, PVC material water pipe and feed trough, ball type nipple drinker, pressure reducer
3: You also can choose automatic system, such as: automatic feeding , manure cleaning system and ventilation cooling system.
Cold/Hot dipped galvanzied baby chick cage include :
(1)A type automatic broiler battery chicken cage
(2)3,4,Tiers
(3)Q235 double cold galvanized anti-corrosion
(4)Q235 national standard double cold galvanized bridge steel cage,
(5)white PVC feed trough,
(6)ball type automatic water equipment ,
(7)white PVC pipe ,
(8)3MM U type galvanized steel shelves,
(9)closed-end pressure-reducer;
(10)Al-Zn material feeding system,
(11)AL-Zn material manure cleaning system,
(12)ventilation system,lighting system,
(13)environment contronlling system.
Full automatic system of baby chick cage:
1:H type battery pullet/broiler cage
2:3tiers, 4tiers,5 tiers, 6tiers, 8tiers
3:Q235 double hot galvanized anti-corrosion
4:Q235 national standard double hot galvanized bridge steel cage,hot galvanized steel feed trough,ball type automatic water equipment ,white PVC pipe ,3MM U type galvanized steel shelves,closed-end pressure-reducer;Al-Zn material feeding system,AL-Zn material manure cleaning system,ventilation system,lighting system,environment controlling system and so on.
Baby chick cage specification :
| Tier | Cell size | Whole size | Capacity/set | Average area/bird |
| 3-tiers | 61*50*35cm | 183*230*150cm | 126 birds(2 kgs) | 435.7 cm2 |
| 4-tiers | 61*50*35cm | 183*265*170cm | 168 birds(2kgs) | 435.7 cm2 |
