Galvanized Welded Wire Chicken Cages
Product Description:
(1)Tiers:3,4,5,6,8 leves/floors
(2)Material:Q235 Hot-Dipped Galvanized,Zinc thickness: 275g/㎡
(3)Frame:Material of leg of frame is hot-dip galvanized steel with thickness: 2mm
(4)Feed trough:Material: hot-dip galvanized steel. Thickness: 1.0mm.
(5)Design:Fully Automatic Poultry Breeding Layer Egg Chicken Cage Equipment
(6)Fully Automatic System Including Egg Chicken Farm Layer Chicken Cages Body,Egg Layer Chicken Hens Battery Cage Frame,Feeders,automatic drinking system,on-rail hopper feeding system,manure removal stystem,egg collection system,Ventilation System etc
| H Type Laying Hens Cage |
| Cage size | Door No. /cage | Chicken No. /door | No. of tiers | Birds qty/set | Area per bird (cm2/bird) | Each door Size(mm) | Unit Cage Size(mm) |
| 1800*600*430 | 4 | 6 | 3 | 144 | 450 | 450x600x430 | 1800x1200x2140 |
| 1800*600*430 | 4 | 6 | 4 | 192 | 450 | 450x600x430 | 1800x1200x2790 |
| 1800*600*430 | 4 | 6 | 5 | 240 | 450 | 450x600x430 | 1800x1200x3440 |
| 1800*600*430 | 4 | 6 | 6 | 288 | 450 | 450x600x430 | 1800x1200x4090 |
| 1800*600*430 | 4 | 6 | 8 | 384 | 450 | 450x600x430 | 1800x1200x5390 |
| Full sets including laying chicken hens cage body, automatic hopper feeding system, automatic drinking system, automatic manure removal system, automatic egg collecting system, ventilation system, lighting system, environmental control system |
| Egg collection machine | Hot-dip galvanized 1.5mm side plate,speed 4m/min. |
| Egg conveying belt | Belt is used for conveeying the eggs to egg collection machine; Imported from Italy; Material is PP woven belt,thickness 2mm,Width 100mm. |
| Clip for egg collecting belt | Material:PVC,4pcs/set,to fasten the egg belt |
| Egg guider | Hot galvanized,1mm thickness,configuration with stretching device. |
Our Advantage:
1. We have more than 30 years of production experience, and we are constantly innovating our products
2. we have professional poultry house designers, poultry battery cage designers to help you design poultry shed, and provide you free construction drawings.
3. we have a professional veterinarian to provide you with breeding advice and answers to your problems in the process of
breeding.
4. More than ten years of experience in the animal husbandry industry, no matter you have any questions about poultry,
we can solve for you.
5. Our products have passed ISO 9001 quality certification, our products quality is assured totally.
6. International Q235 bridge steel, good elasticity, no deformation, life span no sag, using double galvanizing technology, no
rust. The scientific design of the poultry cage can relieve the fatigue of the chicken, increase the egg laying rate, reasonable space arrangement, so that the accident casualty rate of the chicken will be the lowest, the damage to the egg ratio is zero.Our high quality products have a service life of more than 20 years.
Product Tags:
|
|
Welded Wire H Type Layer Chicken Cage Q235A Galvanized 2mm Chicken Farm Cage Images
|
