Product Description:
Battery Chicken Cages are designed to provide maximum comfort and convenience for chickens, while ensuring their safety and wellbeing. Our Battery Chicken Cage is equipped with an Automatic Feeding System that ensures timely and sufficient food supply for the poultry. The cage is designed with a Standard Size that is suitable for many chicken breeds. It further features 3-4 Doors, allowing easy access for poultry. The cage has a Capacity of up to 90-160 Chickens, making it an ideal choice for medium and large farms. Moreover, the Battery Chicken Cage is equipped with a Ventilation System to maintain a healthy and comfortable environment for the birds.
Features:
1. The mesh is smooth to prevent foot infections from injured chickens.
2. Encryption of the partition net and the bottom net can effectively prevent the fatigue syndrome of pecking feathers and anus and laying hens.
3. The mesh is galvanized to increase the service life. (Currently galvanizing is divided into cold galvanized, hot-dip galvanized wire, and hot galvanizing )
4. High-density breeding saves land, is conducive to epidemic prevention and reduces the incidence of poultry diseases.
5. The unique large door reinforcement design effectively prevents the chickens from shaking their heads and wasting feed when they eat. The space of the cage door is enlarged, which is convenient for various operations of the chicken.
6. Expansibility: It can be adjusted appropriately according to the size of the venue, and automatic drinking water system can be matched;
7. The chicken manure conveyor belt is installed at the bottom, which effectively solves the pollution in the chicken house, and directly transports the manure to the outdoors, reducing manual input.
Technical Parameters:
(1)A type automatic broiler battery chicken cage
(2)3,4,Tiers
(3)Q235 double cold galvanized anti-corrosion
(4)Q235 national standard double cold galvanized bridge steel cage,
(5)white PVC feed trough,
(6)ball type automatic water equipment ,
(7)white PVC pipe ,
(8)3MM U type galvanized steel shelves,
(9)closed-end pressure-reducer;
(10)Al-Zn material feeding system,
(11)AL-Zn material manure cleaning system,
(12)ventilation system,lighting system,
(13)environment contronlling system.
| A Type Layer Chicken Cage |
| Cage size/cm | Door No. /cage | Chicken No. /door | No. of tier | Birds Qty/set | Area per bird (cm2/bird) | Each door size(cm) | Unit cage size(cm) |
| 195*38*38 | 5 | 3 | 3 | 90 | 494 | 39x38x38 | 195x230x150 |
| 195*38*38 | 5 | 3 | 4 | 120 | 494 | 39x38x38 | 195x230x190 |
| 195*41*41 | 5 | 4 | 3 | 90 | 533 | 39x41x41 | 195x230x160 |
| 195*41*41 | 5 | 4 | 4 | 120 | 533 | 39x41x41 | 195x230x200 |
| 195*41*41 | 4 | 4 | 3 | 96 | 499 | 48.7x41x41 | 195x230x160 |
| 195*41*41 | 4 | 4 | 4 | 128 | 499 | 48.7x41x41 | 195x230x200 |
| 195*45*41 | 5 | 4 | 3 | 120 | 438 | 39x45x41 | 195x236x160 |
| 195*45*41 | 5 | 4 | 4 | 160 | 438 | 39x45x41 | 195x236x200 |
| 172x41x41 | 4 | 4 | 3 | 96 | 440 | 43x41x41 | 172x230x160 |
| 172x41x41 | 4 | 4 | 4 | 128 | 440 | 43x41x41 | 172x230x200 |
| 215x41x41 | 5 | 4 | 3 | 120 | 440 | 43x41x41 | 215x230x160 |
| 215x41x41 | 5 | 4 | 4 | 160 | 440 | 43x41x41 | 215x230x200 |
| 215x45x41 | 5 | 4 | 3 | 120 | 484 | 43x45x41 | 215x236x160 |
| 215x45x41 | 5 | 4 | 4 | 160 | 484 | 43x45x41 | 215x236x200 |
| Full equipment | Layer chicken cage body, Automatic feeding machine, automatic drinking system, automatic egg collection and automatic manure cleaning system |
Support and Services:
Battery Chicken Cage Technical Support and Service
Our technical support team is available to provide support and troubleshooting for Battery Chicken Cage. We can provide help with setup, advice on maintenance, and answer any questions you may have.
Installation and Maintenance
We can provide installation and maintenance services for your Battery Chicken Cage. Our team can help you set up the cage and ensure it is operating correctly, as well as provide ongoing maintenance and repairs.
Consultation and Advice
Our team can provide advice and consultation on how to get the most out of your Battery Chicken Cage. We can help you with advice on the best practices for housing and feeding your chickens, as well as answer any questions you may have about the cage.
