A Type Galvanized Broiler Baby Chick Cage
Manure cleaning system baby chick cage:
You can choose automatic manure cleaning system or not
We have 2 kinds of manure cleaning machine :
Belt type feeding machine
Scraper type feeding machine
Conveyor belt type of the automatic manure removing system can reduce the labor intensity and labor costs,make it convenient to clean up manure timely,keep the chicken house dry and improve the manure utilization.
If more than 10000 broilers one house I suggest you use belt type manure cleaning machine
Why to choose cage raising chicken ?
1:The environment of chicken house is controllable, which is conducive to the physiological and production needs of chicken.
2: Automatic drinking, feeding, manure cleaning, eggs collecting, saving manpower, reducing raising cost, multi-layer cage saves more space than floor raising, high land utilization rate, saving chicken house construction and land cost.
3: Due to the good isolation between the close chicken house and the outside , the chance of cross contamination of chickens will be greatly reduced, which is conducive to the prevention and control of epidemic diseases, and save the cost of epidemic prevention.
Full automatic system of baby chick cage:
1:H type battery pullet/broiler cage
2:3tiers, 4tiers,5 tiers, 6tiers, 8tiers
3:Q235 double hot galvanized anti-corrosion
4:Q235 national standard double hot galvanized bridge steel cage,hot galvanized steel feed trough,ball type automatic water equipment ,white PVC pipe ,3MM U type galvanized steel shelves,closed-end pressure-reducer;Al-Zn material feeding system,AL-Zn material manure cleaning system,ventilation system,lighting system,environment controlling system and so on.
Baby chick cage specification :
| Tier | Cell size | Whole size | Capacity/set | Average area/bird |
| 3-tiers | 61*50*35cm | 183*230*150cm | 126 birds(2 kgs) | 435.7 cm2 |
| 4-tiers | 61*50*35cm | 183*265*170cm | 168 birds(2kgs) | 435.7 cm2 |
