85*62.5*50 Cm Size H Type Broiler Chicken Cage
Professional after-sales team:
1.We have 30 years of experience in professional design drawing team, and we are committed to product development and upgrading all year round. We can provide design drawings for free, and can design the scheme according to the requirements of different customers.
2.We have professional installation team with many years of foreign installation experience, After you ordered chicken poultry equipment, we can go to your country to provide guidance for installation until your equipment is in normal operation. We will visit our customers every year, which can better solve the problems encountered by customers in use.
Why to choose cage raising chicken ?
1:The environment of chicken house is controllable, which is conducive to the physiological and production needs of chicken.
2: Automatic drinking, feeding, manure cleaning, eggs collecting, saving manpower, reducing raising cost, multi-layer cage saves more space than floor raising, high land utilization rate, saving chicken house construction and land cost.
3: Due to the good isolation between the close chicken house and the outside , the chance of cross contamination of chickens will be greatly reduced, which is conducive to the prevention and control of epidemic diseases, and save the cost of epidemic prevention.
Full automatic system of battery chicken cage:
1:H type battery pullet/broiler cage
2:3tiers, 4tiers,5 tiers, 6tiers, 8tiers
3:Q235 double hot galvanized anti-corrosion
4:Q235 national standard double hot galvanized bridge steel cage,hot galvanized steel feed trough,ball type automatic water equipment ,white PVC pipe ,3MM U type galvanized steel shelves,closed-end pressure-reducer;Al-Zn material feeding system,AL-Zn material manure cleaning system,ventilation system,lighting system,environment controlling system and so on.
Broiler chicken cage specification :
| Tier | Cell size | Whole size | Capacity/set | Average area/bird |
| 3-tiers | 85*62.5*50 cm | 85*220*260 cm | 102 birds(1.5 kgs) | 312.5 cm2 |
| 4-tiers | 85*62.5*50 cm | 85*220*325 cm | 136 birds(1.5 kgs) | 312.5 cm2 |
| 5-tiers | 85*62.5*50 cm | 85*220*390 cm | 170 birds(1.5 kgs) | 312.5 cm2 |
| 6-tiers | 85*62.5*50 cm | 85*220*455 cm | 204 birds(1.5 kgs) | 312.5 cm2 |
| 8-tiers | 85*62.5*50 cm | 85*220*585 cm | 272 birds(1.5 kgs) | 312.5 cm2 |
